700Cc Single-Cylinder Engine

Electric Power Steering: Superior Sport Handling & Precise Control

Storage Bin

Electrically Selectable 4WD & Rear Differential Lock

Beefy 25” Tyres

Digital Instrumentation
Engine
Engine type
Liquid-cooled, 4-stroke, single-cylinder
Displacement
695 cm³
Bore x stroke
102.0 x 85.0 mm
Compression ratio
10.3:1
Fuel system
Fuel injection: 44 mm x 1
Starting System
Electric
Lubrication
Forced lubrication, wet sump
Brakes & Suspension
Brakes, front
Hydraulic disc
Brakes, rear
Hydraulic disc
Suspension, rear
Double wishbone
Performance & Transmission
Maximum power
32.8 kW {45 PS} / 6,000 rpm
Maximum torque
57.6 N•m {5.8 kgf•m} / 5,000 rpm
Transmission
CVT, 2-speed & reverse, automatic
Final drive
Shaft 2WD/4WD
Frame & Dimensions
Frame type
Tubular double-cradle, high-tensile steel
Wheel travel front
218 mm
Wheel travel rear
232 mm
Tyre, front
25 x 8.00 R12
Tyre, rear
25 x 10.00 R12
Wheelbase
2,005 mm
Fuel capacity
36.0 liter
Seat height
850 mm
Dry weight
685 kg
Curb mass
719 kg
