Bright Headlights

Digital Instrumentation

Tilt Steering

Gas-assisted tilting cargo bed.

Largest Cargo Bed in Class

Powerful 993 cm3 Diesel Engine
Engine
Engine type
Liquid-cooled, 4-stroke, three-cylinder
Displacement
993 cm³
Bore x stroke
74.0 x 77.0 mm
Compression ratio
23.5:1
Fuel system
Fuel injection with in-line
Starting System
Electric
Lubrication
Forced lubrication, wet sump
Brakes & Suspension
Brakes, front
Dual discs
Brakes, rear
Dual discs
Suspension, rear
Double wishbone
Performance & Transmission
Maximum power
17.8 kW {24 PS} / 3,600 rpm
Maximum torque
52.1 N•m {5.3 kgf•m} / 2,400 rpm
Transmission
CVT, 2-speed & reverse, automatic
Final drive
Shaft 2WD/4WD, dual-mode differential
Primary Reduction Ratio
3.334 ~ 0.756
Final reduction ratio
6.382 (31/17 x 35/10) - 6.245 (31/21 x 55/13)
Frame & Dimensions
Frame type
Tubular double-cradle, high-tensile steel
Wheel travel front
222 mm
Wheel travel rear
217 mm (left 217 mm , right 220 mm) - GB
Tyre, front
26 x 9.00-12 4PR
Tyre, rear
26 x 11.00-12 4PR
Wheelbase
2,345 mm
Fuel capacity
30.0 liter
Seat height
885 mm
Dry weight
810 kg
Curb mass
845 kg
